Features

Salford’s Endurance is the definition of excellence among litter spreaders on the market today. This pull-type spreader provides precision in targeted delivery of organic nutrients and is ideal for poultry litter, manure, shavings and a variety of other organic materials. The Endurance is a tough, durable spreader that achieves targeted application with a uniform spread pattern. Powered by hydraulics and a spinner system that achieves a wide spread pattern, this pull-type unit is available in lengths ranging from 14’–24’ and made to get the job done when it comes to spreading a range from light to heavy materials on farms of all sizes.

• Hydraulic Binary Manifold with pilot operated relief, manual flow controls for spinner and conveyor,
conveyor dump valve
• Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)
• 35-gallon hydraulic reservoir with fill, sight window, temp gauge, drain and vent
• Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)
• Tandem conveyor drive gearbox
• 6 x 1/4″ spinner fins per spinner
• 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
• Hopper-on-frame construction (bolt-down)
• Dual rack-and-pinion gate (prevents jamming)
• 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar)

Endurance MaterialsIdeal for livestock and poultry farmers or custom applicators, the BBI Endurance will spread a variety of materials.

  • Chicken litter
  • Turkey litter
  • Beet lime
  • Lime
  • Bark
  • Wood chips
  • Shavings
  • Pelletized material

Endurance Hopper ProfileLOW PROFILE HOPPER has a capacity of 16 cu/ft. struck level per linear ft., at 88 in. wide and 45.5 in high

STANDARD PROFILE HOPPER has a capacity of 20 cu/ft. struck level per linear foot, at 88 in. wide and 51.5 in. high

HIGH PROFILE HOPPER has a capacity of 23.5 cu/ft. struck level per linear foot, at 88 in. wide and 57.5 in. high

WIDE HOPPER has a capacity of 21 cu/ft. struck level per linear foot, at 96 in. wide and 52 in. high.

Endurance SuspensionOption rich Endurance model offers Torsion Axle or Walking Beam suspension types available for a variety of tire sizes and hopper construction choices.

Endurance Lime PackageNow more than ever, the Endurance gives you greater return on investment through more choice on the farm, with heave duty lime packages available. Greater versatility for greater economic performance, season to season.

Close bar conveyor chain (Bars every other link)

Center-V

Single Tandem Gear Case

HIGH PERFORMANCE LIME SPREADER PACKAGE

3rd run 88k conveyor chain

Over-slung center-V

Poly Floor UHMW

2 Tandem gear cases

Walking beam suspension

Product Specs

Series
BBI BBI BBI BBI BBI
Size
240 cu-ft, 304 cu-ft, 368 cu-ft , 400 cu-ft 270 cu-ft, 342 cu-ft, 414 cu-ft , 450 cu-ft 300 cu-ft, 380 cu-ft, 460 cu-ft , 500 cu-ft 330 cu-ft, 418 cu-ft, 506 cu-ft , 550 cu-ft 360 cu-ft, 456 cu-ft, 552 cu-ft , 550 cu-ft
Product type
Pull Type Spinner Spreaders Pull Type Spinner Spreaders Pull Type Spinner Spreaders Pull Type Spinner Spreaders Pull Type Spinner Spreaders
Model Name Short
Endurance 16-ft Endurance 18-ft Endurance 20-ft Endurance 22-ft Endurance 24-ft
Model Name Long
Endurance 16' Tandem Axle Spreader Endurance 18' Tandem Axle Spreader Endurance 20' Tandem Axle Spreader Endurance 22' Tandem Axle Spreader Endurance 24' Tandem Axle Spreader

Materials Spread

Fertilizer
NO NO NO NO NO
AG Lime
YES YES YES YES YES
Litter
YES YES YES YES YES
Organics
YES YES YES YES YES
Seed
NO NO NO NO NO
Other
Chick Litter and Composted Manure Chick Litter and Composted Manure Chick Litter and Composted Manure Chick Litter and Composted Manure Chick Litter and Composted Manure
Number of products applied, including optional hopper compartments
1 1 1 1 1

Detailed Equipment Specifications

Paint

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Jack
Heavy-duty tongue jack Heavy-duty tongue jack Heavy-duty tongue jack Heavy-duty tongue jack Heavy-duty tongue jack
Tarp

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Tail Light

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Height
- - - - -
Weight
- - - - -

Hopper

Hopper Size

16′ LOW PROFILE Hopper 240 cu-ft (88″ wide x 45.5″ high)
16′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
16′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
16′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

18′ LOW PROFILE Hopper 270 cu-ft (88″ wide x 45.5″ high)
18′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
18′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
18′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

20′ LOW PROFILE Hopper 300 cu-ft (88″ wide x 45.5″ high)
20′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
20′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
20′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

22′ LOW PROFILE Hopper 330 cu-ft (88″ wide x 45.5″ high)
22′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
22′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
22′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

24′ LOW PROFILE Hopper 360 cu-ft (88″ wide x 45.5″ high)
24′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
24′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
24′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

Hopper Material

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Hopper Extensions

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Hopper Gate Control

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Hopper Ladder

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Hopper "Inverted V"

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Hopper Sight Window

Yes

Yes

Yes

Yes

Yes

Metering and Drive

PTO Drive

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Material Distribution Booms/Spinners/Air Line

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

Application Swath Width

Lime and Little: Up to 50 feet

Lime and Little: Up to 50 feet

Lime and Little: Up to 50 feet

Lime and Little: Up to 50 feet

Lime and Little: Up to 50 feet

Material Distribution Drive

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Metering Drive

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Primary Metering

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Primary Metering Minimum Output Rate
- - - - -
Primary Metering Maximum Output Rate
- - - - -
Secondary Metering

N/A

N/A

N/A

N/A

N/A

Secondary Metering Minimum Output Rate
- - - - -
Secondary Metering Maximum Output Rate
- - - - -
Material Banding or Section Control

N/A

N/A

N/A

N/A

N/A

Tires and Axles

Axle
- - - - -
Tire and Wheel Options
- - - - -

Monitoring and Precision Control

Monitors Options and Rate Control
- - - - -
Weigh System Option
- - - - -

Compare

Select up to 3 products to compare specifications

Endurance Spreader

Add Model & Size

Choose Model & Size

Product Specs

Series
BBI
Size
240 cu-ft, 304 cu-ft, 368 cu-ft , 400 cu-ft
Product type
Pull Type Spinner Spreaders
Model Name Short
Endurance 16-ft
Model Name Long
Endurance 16' Tandem Axle Spreader

Materials Spread

Fertilizer
NO
AG Lime
YES
Litter
YES
Organics
YES
Seed
NO
Other
Chick Litter and Composted Manure
Number of products applied, including optional hopper compartments
1

Detailed Equipment Specifications

Paint

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray

Hitch

Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch
Cat 4 Articulating Hitch

Jack
Heavy-duty tongue jack
Tarp

Standard: No Tarp
Optional: Roll Top Mesh Tarp, Manual control

Tail Light

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Height
-
Weight
-

Hopper

Hopper Size

16′ LOW PROFILE Hopper 240 cu-ft (88″ wide x 45.5″ high)
16′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high)
16′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high)
16′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)

Hopper Material

Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors

Standard: Steel Floor
Optional: Poly Floor

Hopper Extensions

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Hopper Gate Control

Dual rack-and-pinion gate (prevents jamming)
Stanard: Manual Operated Gate
Optional: Hydraulic Gate (dual cylinders)

Hopper Ladder

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper

Hopper "Inverted V"

Standard: No Invertered V
Optional: Removeable Invertered V
* The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.

Hopper Sight Window

Yes

Metering and Drive

PTO Drive

Choice:
540 RPM Series 6 CV Joint PTO Shaft STANDARD
1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD
1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD
No PTO – Plug to Tractor

Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)

Material Distribution Booms/Spinners/Air Line

6 x 1/4″ spinner fins per spinner
Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)

Application Swath Width

Lime and Little: Up to 50 feet

Material Distribution Drive

Standard: Self Contained PTO Hydraulics
Optional: Plug to Tractor Hydraulics

Metering Drive

Tandem conveyor drive gearbox
Optional: High Speed Conveyor Valve

Primary Metering

Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar).
Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.

Primary Metering Minimum Output Rate
-
Primary Metering Maximum Output Rate
-
Secondary Metering

N/A

Secondary Metering Minimum Output Rate
-
Secondary Metering Maximum Output Rate
-
Material Banding or Section Control

N/A

Tires and Axles

Axle
-
Tire and Wheel Options
-

Monitoring and Precision Control

Monitors Options and Rate Control
-
Weigh System Option
-

Downloads

BBI Literature

English

BBI Literature

French

BBI Operator Manuals
