Aerway Harrow Attachements

Aerway Harrow Attachments

Features



Standard Features:

  • 500 series no-till row units

Tires:

  • 30' - Main Frame and Wings


Specifications

AWST FRAME CONFIGURATIONS - Straight Frame
C-FLEX AerWay ® – available in 7.50” (0.19 m) effective tine spacing
Model Number Cultivation Width Travel Width # of tines Weight HP Required
AWST100 10’ (3.05 m) 9’ 8” (2.95 m) 64 2225 lbs
(1.01 T)
60-100
AWST125 12.5’ (3.81 m) 12’ 2” (3.71 m) 80 2515 lbs
(1.14 T)
75-125
AWST150 15’ (4.57 m) 14’ 8” (4.47 m) 96 2800 lbs
(1.27 T)
90-150
AWST200 20’ (6.10 m) 19’ 8” (5.99 m) 129 4200 lbs
(1.91 T)
120-200
CCT AerWay ® – available in 3.75” or 5.00” effective tine spacing
Model Number Cultivation Width Travel Width # of Tines 3.75”, 5.00”
(0.10 m, 0.13 m)
Weight HP Required
AWST100-CCT 10’ (3.05 m) 10’ (3.05 m) 96, 72 3150 lbs
(1.43 T)
90-150
AWST125-CCT** 12.5’ (3.81 m) 12.5’ (3.81 m) 120, N/A 3725 lbs
(1.69 T)
115-19
AWST150-CCT 15’ (4.57 m) 15’ (4.57 m) 144, 108 4300 lbs
(1.95 T)
135-225
AWST200-CCT 20’ (6.10 m) 20’ (6.10 m) 192, 144 6000 lbs
(2.72 T)
180-300
** NOT AVAILABLE IN 5.00" TINE SPACING
AWFT FRAME CONFIGURATIONS - Folding Frame
C-FLEXSINGLE ROW AerWay ® – available in 7.50” (0.19 m) effective tine spacing
Model Number Cultivation Width Travel Width # of tines Weight HP Required
AWFT200 20' (6.10 m) 10’ 9” (3.28 m) 128 5475 lbs
(2.48 T)
120-200
AWFT25N 25’ (7.62 m) 10’ 9” (3.28 m) 160 6300 lbs
(2.86 T)
150-250
AWFT25W 25’ (7.62 m) 15’ 9” (4.80 m) 160 6300 lbs
(2.86 T)
150-250
AWFT300 30’ (9.14 m) 15’ 9” (4.80 m) 192 7125 lbs
(3.23 T)
180-300
CCT AerWay ® – available in 3.75” or 5.00” (0.10 m or 0.13 m) effective tine spacing
Model Number Cultivation Width Travel Width # of Tines 3.75”, 5.00”
(0.10 m, 0.13 m)
Weight HP Required
AWFT200-CCT 20’ (6.10 m) 10’9” (3.28 m) 192, 144 6950 lbs
(3.15 T)
180-300
AWFT25N-CCT 25’ (7.62 m) 10’ 9” (3.28 m) 210, 180 8100 lbs
(3.67 T)
225-375
AWFT25W-CCT 25’ (7.62 m) 15’9” (4.80 m) 240, 180 8100 lbs
(3.67 T)
225-375
AWFT300-CCT 30’ (9.14 m) 15’ 9” (4.80 m) 288, 216 9225 lbs
(4.18 T)
270-450
