Endurance Spreader

Application • Pull Type Spinner Spreaders

Features

Salford’s Endurance is the definition of excellence among litter spreaders on the market today. This pull-type spreader provides precision in targeted delivery of organic nutrients and is ideal for poultry litter, manure, shavings and a variety of other organic materials. The Endurance is a tough, durable spreader that achieves targeted application with a uniform spread pattern. Powered by hydraulics and a spinner system that achieves a wide spread pattern, this pull-type unit is available in lengths ranging from 14’–24’ and made to get the job done when it comes to spreading a range from light to heavy materials on farms of all sizes.

• Hydraulic Binary Manifold with pilot operated relief, manual flow controls for spinner and conveyor,
conveyor dump valve
• Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)
• 35-gallon hydraulic reservoir with fill, sight window, temp gauge, drain and vent
• Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)
• Tandem conveyor drive gearbox
• 6 x 1/4″ spinner fins per spinner
• 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window
• Hopper-on-frame construction (bolt-down)
• Dual rack-and-pinion gate (prevents jamming)
• 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar)

Ideal for livestock and poultry farmers or custom applicators, the BBI Endurance will spread a variety of materials.

Chicken litter
Turkey litter
Beet lime
Lime
Bark
Wood chips
Shavings
Pelletized material

LOW PROFILE HOPPER has a capacity of 16 cu/ft. struck level per linear ft., at 88 in. wide and 45.5 in high

STANDARD PROFILE HOPPER has a capacity of 20 cu/ft. struck level per linear foot, at 88 in. wide and 51.5 in. high

HIGH PROFILE HOPPER has a capacity of 23.5 cu/ft. struck level per linear foot, at 88 in. wide and 57.5 in. high

WIDE HOPPER has a capacity of 21 cu/ft. struck level per linear foot, at 96 in. wide and 52 in. high.

Option rich Endurance model offers Torsion Axle or Walking Beam suspension types available for a variety of tire sizes and hopper construction choices.

Now more than ever, the Endurance gives you greater return on investment through more choice on the farm, with heave duty lime packages available. Greater versatility for greater economic performance, season to season.

Close bar conveyor chain (Bars every other link)

Center-V

Single Tandem Gear Case

HIGH PERFORMANCE LIME SPREADER PACKAGE

3rd run 88k conveyor chain

Over-slung center-V

Poly Floor UHMW

2 Tandem gear cases

Walking beam suspension

Contact Us Form

"*" indicates required fields

First Name * Last Name *

Phone Number*

Email*

State/Provice*

Postal code*

How can we help you?*

Salford Model Line

Message to Salford

Phone

This field is for validation purposes and should be left unchanged.

Specs Compare

Product Specs

Series	BBI	BBI	BBI	BBI	BBI	BBI
Size	210 cu-ft, 266 cu-ft, 322 cu-ft , 350 cu-ft	240 cu-ft, 304 cu-ft, 368 cu-ft , 400 cu-ft	270 cu-ft, 342 cu-ft, 414 cu-ft , 450 cu-ft	300 cu-ft, 380 cu-ft, 460 cu-ft , 500 cu-ft	330 cu-ft, 418 cu-ft, 506 cu-ft , 550 cu-ft	360 cu-ft, 456 cu-ft, 552 cu-ft , 550 cu-ft
Product type	Pull Type Spinner Spreaders	Pull Type Spinner Spreaders	Pull Type Spinner Spreaders	Pull Type Spinner Spreaders	Pull Type Spinner Spreaders	Pull Type Spinner Spreaders
Model Name Short	Endurance 14-ft	Endurance 16-ft	Endurance 18-ft	Endurance 20-ft	Endurance 22-ft	Endurance 24-ft
Model Name Long	Endurance 14' Tandem Axle Spreader	Endurance 16' Tandem Axle Spreader	Endurance 18' Tandem Axle Spreader	Endurance 20' Tandem Axle Spreader	Endurance 22' Tandem Axle Spreader	Endurance 24' Tandem Axle Spreader
Materials Spread
Fertilizer	NO	NO	NO	NO	NO	NO
AG Lime	YES	YES	YES	YES	YES	YES
Litter	YES	YES	YES	YES	YES	YES
Organics	YES	YES	YES	YES	YES	YES
Seed	NO	NO	NO	NO	NO	NO
Other	Chick Litter and Composted Manure	Chick Litter and Composted Manure	Chick Litter and Composted Manure	Chick Litter and Composted Manure	Chick Litter and Composted Manure	Chick Litter and Composted Manure
Number of products applied, including optional hopper compartments	1	1	1	1	1	1
Detailed Equipment Specifications
Paint	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray
Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch
Jack	Heavy-duty tongue jack	Heavy-duty tongue jack	Heavy-duty tongue jack	Heavy-duty tongue jack	Heavy-duty tongue jack	Heavy-duty tongue jack
Tarp	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control
Tail Light	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit
Height	-	-	-	-	-	-
Weight	-	-	-	-	-	-
Hopper
Hopper Size	14′ LOW PROFILE Hopper 210 cu-ft (88″ wide x 45.5″ high) 14′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 14′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 14′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)	16′ LOW PROFILE Hopper 240 cu-ft (88″ wide x 45.5″ high) 16′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 16′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 16′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)	18′ LOW PROFILE Hopper 270 cu-ft (88″ wide x 45.5″ high) 18′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 18′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 18′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)	20′ LOW PROFILE Hopper 300 cu-ft (88″ wide x 45.5″ high) 20′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 20′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 20′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)	22′ LOW PROFILE Hopper 330 cu-ft (88″ wide x 45.5″ high) 22′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 22′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 22′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)	24′ LOW PROFILE Hopper 360 cu-ft (88″ wide x 45.5″ high) 24′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 24′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 24′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)
Hopper Material	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor
Hopper Extensions	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards
Hopper Gate Control	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)
Hopper Ladder	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper
Hopper "Inverted V"	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.
Hopper Sight Window	Yes	Yes	Yes	Yes	Yes	Yes
Metering and Drive
PTO Drive	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)
Material Distribution Booms/Spinners/Air Line	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)
Application Swath Width	Lime and Little: Up to 50 feet	Lime and Little: Up to 50 feet	Lime and Little: Up to 50 feet	Lime and Little: Up to 50 feet	Lime and Little: Up to 50 feet	Lime and Little: Up to 50 feet
Material Distribution Drive	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics
Metering Drive	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve
Primary Metering	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.
Primary Metering Minimum Output Rate	-	-	-	-	-	-
Primary Metering Maximum Output Rate	-	-	-	-	-	-
Secondary Metering	N/A	N/A	N/A	N/A	N/A	N/A
Secondary Metering Minimum Output Rate	-	-	-	-	-	-
Secondary Metering Maximum Output Rate	-	-	-	-	-	-
Material Banding or Section Control	N/A	N/A	N/A	N/A	N/A	N/A
Tires and Axles
Axle	-	-	-	-	-	-
Tire and Wheel Options	-	-	-	-	-	-
Monitoring and Precision Control
Monitors Options and Rate Control	-	-	-	-	-	-
Weigh System Option	-	-	-	-	-	-

Compare

Select up to 3 products to compare specifications

Endurance Spreader

Add Model & Size

Choose Model & Size

1 2

Product Specs

Series	BBI
Size	210 cu-ft, 266 cu-ft, 322 cu-ft , 350 cu-ft
Product type	Pull Type Spinner Spreaders
Model Name Short	Endurance 14-ft
Model Name Long	Endurance 14' Tandem Axle Spreader
Materials Spread
Fertilizer	NO
AG Lime	YES
Litter	YES
Organics	YES
Seed	NO
Other	Chick Litter and Composted Manure
Number of products applied, including optional hopper compartments	1
Detailed Equipment Specifications
Paint	Standard Paint Color – Red Optional Paint Color – Green Optional Paint Color – Gray
Hitch	Standard: Cat 4 Cast Hitch Option – Includes Pintle and Clevis Hitch Cat 4 Articulating Hitch
Jack	Heavy-duty tongue jack
Tarp	Standard: No Tarp Optional: Roll Top Mesh Tarp, Manual control
Tail Light	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit
Height	-
Weight	-
Hopper
Hopper Size	14′ LOW PROFILE Hopper 210 cu-ft (88″ wide x 45.5″ high) 14′ STANDARD Hopper 266 cu-ft (88″ wide x 51.5″ high) 14′ HIGH PROFILE Hopper 322 cu-ft (88″ wide x 57.5″ high) 14′ WIDE PROFILE Hopper 350 cu-ft (96″ wide x 52″ high)
Hopper Material	Standard: 10-gauge hopper with 7-gauge rails, 45-degree hopper sides, sight window Optional: 7 Gauge Carbon Steel Hopper with 1/4″ Rails & Floors Standard: Steel Floor Optional: Poly Floor
Hopper Extensions	Standard: No Extension Brackets Optional: Extension Brackets for 6″ boards
Hopper Gate Control	Dual rack-and-pinion gate (prevents jamming) Stanard: Manual Operated Gate Optional: Hydraulic Gate (dual cylinders)
Hopper Ladder	Standard: No Hopper Ladder Optional: Ladder for Carbon Steel Hopper
Hopper "Inverted V"	Standard: No Invertered V Optional: Removeable Invertered V * The Inverted V running along the length of the hopper help prevent material from bridging in the hopper.
Hopper Sight Window	Yes
Metering and Drive
PTO Drive	Choice: 540 RPM Series 6 CV Joint PTO Shaft STANDARD 1000 RPM Series 6 CV 1 3/4 20 Spline STANDARD 1000 RPM Series 6 CV 1 3/8 21 Spline STANDARD No PTO – Plug to Tractor Heavy-duty 2-section hydraulic pump (on-self contained hydraulic units)
Material Distribution Booms/Spinners/Air Line	6 x 1/4″ spinner fins per spinner Proprietary 2 1/2″ spinner motors (provides optimal pressure seal protection)
Application Swath Width	Lime and Little: Up to 50 feet
Material Distribution Drive	Standard: Self Contained PTO Hydraulics Optional: Plug to Tractor Hydraulics
Metering Drive	Tandem conveyor drive gearbox Optional: High Speed Conveyor Valve
Primary Metering	Standard: 34″ conveyor with 88K heavy-duty chain, bars every other link (close bar). Optional: Add a 3rd run of 88K chain. Bars are every other link. Includes UHMW rear roller support.
Primary Metering Minimum Output Rate	-
Primary Metering Maximum Output Rate	-
Secondary Metering	N/A
Secondary Metering Minimum Output Rate	-
Secondary Metering Maximum Output Rate	-
Material Banding or Section Control	N/A
Tires and Axles
Axle	-
Tire and Wheel Options	-
Monitoring and Precision Control
Monitors Options and Rate Control	-
Weigh System Option	-
