HALO VRT

Features

The HALO VRT is the industry’s first variable-rate tillage design on a forward folding, high-speed disk frame that is designed to perform the job of multiple tillage machines faster and more efficiently. A high-speed disc, the HALO VRT offers adjustable blade angles to adapt to any field condition with complete control from the tractor cab to choose tillage intensity, narrow transport to safely and easily move between farms and fields and a complete field finishing package to achieve the best results. Whether adjustments are needed in the field, from field to field, or from season to season the HALO VRT performs the work of multiple tillage machines in one simple-to-operate platform.

Experience unmatched versatility and durability with Salford’s latest innovation. The 15ft HALO VRT is designed for farms of all sizes, bringing top-tier performance to your fields. Adjust the blade angle on the go to tackle any field condition with ease from your cab. Built with Salford’s renowned durability, this machine ensures reliable performance season after season. Its narrow transport design enables quick and easy movement between fields, maximizing your time and effort.

The 15ft HALO VRT offers powerful versatility for every farm, field, and tractor

Salford Halo VRT in fieldThe HALO VRT performs the work of multiple tillage machines in one simple-to-operate platform. With hydraulically adjustable blades, the VRT allows the producer to choose their tillage intensity on the fly from the comfort of the cab. Mounted on 5-inch net spacing, the blades have rubber torsion suspension, capable of 7.5″ of travel or obstacle protection in rough and rocky conditions. Each 22-inch, wavy blade is independently mounted, absorbing the shock load and providing excellent soil and residue flow through the machine and an even finish at speeds up to 14 MPH.

The HALO VRT’s wide range of blade angle adjustments allow it to perform Spring and Fall tillage with ease. The operator can choose their tillage intensity on the fly with customized blade adjustments between 2° and 15°, all from the comfort of the cab. These adjustments transform the VRT from a vertical tillage and seedbed prep tool to a fall tillage machine, capable of leveling ruts.

Salford Halo VRT in fieldThe HALO VRT features single point depth control, hydraulic fore / aft leveling and active pressure control on the finishing tool. The VRT’s depth control is completely hydraulic, with no shims or plates required. The operator convenience station keeps implement connections protected, organized and at the operator’s fingertips. The color-coded hose grips take out the guess work when connecting Salford implements to the tractor. The HALO’s narrow, forward-folding design makes the machine safe and easy to transport.

HALO VRT RemoteThe HALO VRT offers optional hydraulic adjustments for blade angle, wing operation (down pressure, float and fold), fore-aft level and jack position. The electro-hydraulic option reduces the need for 5+ hydraulic remotes down to only requiring 3 for operation. All of these adjustments are made from the cab, on-the-go.

Hydraulic circuit on Salford's HALO tillage toolsThe HALO frame system is engineered to level fields with side-to-side and front-to-back hydraulic settings that keep the machine running level.
HALO’s wings can be run with active down pressure. This keeps the machine operating level from side to side and ensures wings stay engaged in tough conditions.
A hydraulic fore / aft leveling system is designed to prevent the high-speed frame from hopping in rough conditions.
HALO’s mainframe has a large pitch indicator easily seen from the cab that makes it easy to see the fore / aft setting and return to the same position field to field.

Salford HALO mainframe tires, 600/50-22.5, and 800/40R22.5HALO models feature flotation tires for maximum field flotation and safe transport. 20-foot through 35-foot machines have 600/50-22.5. 40-foot machines have 800/40-22.5.

HALO models with 30-foot working width and up have wing gauge wheels to keep the machine at the set operating depth. 30-foot models have 500/50R17 gauge wheels, 35 and 40-foot models have 550/45R22.5.

(Left 600/50-22.5. Right 800/40-22.5)

Salford double 14-inch flat bar cage roller finishing system for select HALO tillage modelsDouble 14 inch flat bar rolling basket

The double 14 inch roller provides a finer finish and seedbed, but it’s also heavy enough to size soil clods, condition residue and level. The double 14 inch rollers are carried by 1 1/2 inch maintenance free bearings. The linkage is a simple, maintenance-free system with hardened bushings and pins.

The HALO’s narrow, forward folding frame design is safer and easier to transport between fields. All HALO models can transport under 12-feet wide.

Product Specs

Series
Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage
Product Type
HALO HALO HALO HALO HALO HALO
Model
HALO VRT HALO VRT HALO VRT HALO VRT HALO VRT HALO VRT
Size
15 ft 20 ft 25 ft 30 ft 35 ft 40 ft
Folding (Multi-Section) or Non-Folding
Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section)
Fold Type
Forward Folding 2 Piece Frame Forward Folding 2 Piece Frame Forward Folding 2 Piece Frame Forward Folding 3 Piece Frame Forward Folding 3 Piece Frame Forward Folding 3 Piece Frame

Dimensions and Weights

Working width, ft (m)
14 ft 2 in 19 ft 1 in 24 ft 1 in 29 ft 2 in 34 ft Rubber Torsion Mount in 39 ft Rubber Torsion Mount in
Transport width, ft (m)
9 ft 10 in 11 ft 3 in 11 ft 3 in 11 ft 11 in 11 ft 11 in 11 ft 11 in
Transport height, ft (m)
13 ft 2 in 14 ft 9 in 15 ft 2 in 15 ft 15 ft 1 in 15 ft 1 in
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
12300 18800 21500 28350 31200 34000
Other sizes available, number of widths
20, 25, 30, 35, 40 15, 25, 30, 35, 40 15, 20, 30, 35, 40 15, 20, 25, 35, 40 15, 20, 25, 30, 40 15, 20, 25, 30, 35

Ground Engaging Equipment - Front Row(s)

Front row(s) ground engaging equipment (description)
25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade
Front row(s) ground engaging equipment (quantity)
Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount
Front row(s) equipment quantity
36 24 30 36 42 48
Front row(s) equipment mount
Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount
Equipment spacing, in (mm)
5 in (net) 5 in (net) 5 in (net) 5 in (net) 5 in (net) 5 in (net)
Equipment size, in (mm)
22 in 22 in 22 in 22 in 22 in 22 in
Angle
2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees
Bearings
Double tapered roller bearing. Double tapered roller bearing, - - - -

Ground Engaging Equipment - Rear Row(s)

Rear row(s) ground engaging equipment (description)
25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade 25 wave low concavity blade
Rear row(s) ground engaging equipment (quantity)
Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount
Rear row(s) equipment quantity
36 24 30 36 42 48
Rear row(s) equipment mount
Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount Rubber Torsion Mount
Equipment spacing, in (mm)
5 in (net) 5 in (net) 5 in (net) 5 in (net) 5 in (net) 5 in (net)
Equipment size, in (mm)
22 in 22 in 22 in 22 in 22 in 22 in
Angle
2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees 2-15 degrees
Bearings
Double tapered roller bearing Double tapered roller bearing, - - - -
Equipment options
Multi-function Joystick Control Multi-function Joystick Control Multi-function Joystick Control Multi-function Joystick Control Multi-function Joystick Control Multi-function Joystick Control

Wheels and Tires

Transport wheel mounting
8-bolt 8-bolt 10-bolt 10-bolt 10-bolt 10-bolt
Transport tires
550/45-22.5 600/50R-22.5 600/50R-22.5 600/50R-22.5 800/40R-22.5 800/40R-22.5
Wing wheel mounting
N/A N/A N/A N/A N/A N/A
Wing tires
N/A N/A Optional N/A N/A N/A
Gauge wheel mounting
N/A N/A Optional Manual adjustable gauge wheels Manual adjustable gauge wheels Manual adjustable gauge wheels Manual adjustable gauge wheels
Guage wheel tires
N/A N/A 13.5L-15X31 500/50R-22.5 500/50R-22.5 500/50R-22.5

Hitch

Hookup to tractor, mounted or pull-type
CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch CAT 3 or CAT 4 Standard or Ball Hitch CAT 4 or CAT 5 Standard or Ball Hitch CAT 4 or CAT 5 Standard or Ball Hitch CAT 4 or CAT 5 Standard or Ball Hitch

Depth and Level Adjustment

Typical operating depth, in (mm)
1-5 in 1-5 in 1-5 in 1-5 in 1-5 in 1-5 in
Operating speed (mph)
8-14 mph 8-14 mph 8-14 mph 8-14 mph 8-14 mph 8-14 mph
Depth control
Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control
Fore/aft leveling
Hydraulic fore/aft levelling with accumulator protection Hydraulic fore/aft levelling with accumulator protection Hydraulic fore/aft levelling with accumulator protection Hydraulic fore/aft levelling with accumulator protection Hydraulic fore/aft levelling with accumulator protection Hydraulic fore/aft levelling with accumulator protection

Tractor Requirements

Required power, hp/ft (kw/m)
11-18 hp/ft 11-18 hp/ft 11-18 hp/ft 11-18 hp/ft 11-18 hp/ft 11-18 hp/ft
Remote Hydraulic Values required
5 5 5 5 + 1 5 + 1 5 + 1
Hydraulic Pressure
Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure

Finishing Attachment Options

Option 1
Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller Otico Wave-Profile FarmFlex Rubber Roller
Option 2
Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket Double 14-inch Flat Bar Rolling Basket
Option 3
Heavy Duty Double 14-inch Flat Bar Rolling Basket Heavy Duty Double 14-inch Flat Bar Rolling Basket Heavy Duty Double 14-inch Flat Bar Rolling Basket Heavy Duty Double 14-inch Flat Bar Rolling Basket Heavy Duty Double 14-inch Flat Bar Rolling Basket Heavy Duty Double 14-inch Flat Bar Rolling Basket
Option 4
- - - - - -

Compare

Select up to 3 products to compare specifications

HALO VRT

Add Model & Size

Choose Model & Size

Product Specs

Series
Salford Tillage
Product Type
HALO
Model
HALO VRT
Size
15 ft
Folding (Multi-Section) or Non-Folding
Folding (Multi-Section)
Fold Type
Forward Folding 2 Piece Frame

Dimensions and Weights

Working width, ft (m)
14 ft 2 in
Transport width, ft (m)
9 ft 10 in
Transport height, ft (m)
13 ft 2 in
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
12300
Other sizes available, number of widths
20, 25, 30, 35, 40

Ground Engaging Equipment - Front Row(s)

Front row(s) ground engaging equipment (description)
25 wave low concavity blade
Front row(s) ground engaging equipment (quantity)
Rubber Torsion Mount
Front row(s) equipment quantity
36
Front row(s) equipment mount
Rubber Torsion Mount
Equipment spacing, in (mm)
5 in (net)
Equipment size, in (mm)
22 in
Angle
2-15 degrees
Bearings
Double tapered roller bearing.

Ground Engaging Equipment - Rear Row(s)

Rear row(s) ground engaging equipment (description)
25 wave low concavity blade
Rear row(s) ground engaging equipment (quantity)
Rubber Torsion Mount
Rear row(s) equipment quantity
36
Rear row(s) equipment mount
Rubber Torsion Mount
Equipment spacing, in (mm)
5 in (net)
Equipment size, in (mm)
22 in
Angle
2-15 degrees
Bearings
Double tapered roller bearing
Equipment options
Multi-function Joystick Control

Wheels and Tires

Transport wheel mounting
8-bolt
Transport tires
550/45-22.5
Wing wheel mounting
N/A
Wing tires
N/A
Gauge wheel mounting
N/A
Guage wheel tires
N/A

Hitch

Hookup to tractor, mounted or pull-type
CAT 3 or CAT 4 Standard or Ball Hitch

Depth and Level Adjustment

Typical operating depth, in (mm)
1-5 in
Operating speed (mph)
8-14 mph
Depth control
Single point depth control
Fore/aft leveling
Hydraulic fore/aft levelling with accumulator protection

Tractor Requirements

Required power, hp/ft (kw/m)
11-18 hp/ft
Remote Hydraulic Values required
5
Hydraulic Pressure
Hydraulic wing down pressure, Hydraulic quick set finishing tool pressure

Finishing Attachment Options

Option 1
Otico Wave-Profile FarmFlex Rubber Roller
Option 2
Double 14-inch Flat Bar Rolling Basket
Option 3
Heavy Duty Double 14-inch Flat Bar Rolling Basket
Option 4
-
