Salford’s HALO HSD high-speed disk is engineered for speed, performance, and ease of use. The HALO HSD features maintenance-free blade hubs and advanced seal technology. The HALO HSD is capable of multi-season tillage and operates between 8 and 14-mph to perform superior leveling in less time. The HALO’s individually mounted blades are mounted on a rubber torsion suspension providing maximum clearance and obstacle protection.
Features
The HALO HSD’s individually mounted blades allow for maximum residue and soil flow, while the angled blade mounting arms are designed to keep the HALO HSD at depth in hard ground. The blades have rubber torsion suspension, which are capable of 7.5″ of travel for obstacle protection in rough and rocky conditions. Each 22″ blade is independently mounted, which absorbs the shock load and provides an even finish.
The HALO HSD is simple to set! Quick-set depth control and a quick set control for setting pressure on the finishing tool. The operator station keeps implement connections protected, organized and at the operator’s finger tips. The color coded hose grips take out the guess work when connecting Salford implements to the tractor.
The HALO frame system is engineered to level fields with side-to-side and front-to-back hydraulic settings that keep the machine running level.
HALO’s wings can be run with active down pressure. This keeps the machine operating level from side to side and ensures wings stay engaged in tough conditions.
A hydraulic fore / aft leveling system is designed to prevent the high-speed frame from hopping in rough conditions.
HALO’s mainframe has a large pitch indicator easily seen from the cab that makes it easy to see the fore / aft setting and return to the same position field to field.
HALO models feature flotation tires for maximum field flotation and safe transport. 20-foot through 35-foot machines have 600/50-22.5. 40-foot machines have 800/40-22.5.
HALO models with 30-foot working width and up have wing gauge wheels to keep the machine at the set operating depth. 30-foot models have 500/50R17 gauge wheels, 35 and 40-foot models have 550/45R22.5.
(Left 600/50-22.5. Right 800/40-22.5)
The HALO HSD has three finishing system options. A simple hydraulic pressure adjustment quickly creates the ideal field finish in almost any soil and residue conditions. HALO tools are designed to promote good seed to soil contact by conditioning and sizing residue. The finishing systems further condition and help to evenly distribute residue to improved planting and seeding performance.
Double 14 inch flat bar rolling basket
The double 14 inch roller provides a finer finish and seedbed, but it’s also heavy enough to size soil clods, condition residue and level. The double 14 inch rollers are carried by 1 1/2 inch maintenance free bearings. The linkage is a simple, maintenance-free system with hardened bushings and pins.
23-Inch Round Bar Cage Roller
The heavy-duty roller is designed to size soil clods, condition residue and level the field surface. The roller is carried by a heavy-duty disc-style bearing with a wide inner race for proper alignment and maximum durability.
Otico Wave-Profile Farmflex® Roller
The flexible roller’s ability to shed sticky soil allows it to excel in a variety of soil types, such as heavy clay and gumbo soils. The flexible roller also helps to minimize damage from rocks and obstacles in the field.
The HALO’s narrow, forward folding frame design is safer and easier to transport between fields. All HALO models can transport under 12-feet wide.
Product Specs
Series
|
Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage |
Product Type
|
HALO | HALO | HALO | HALO | HALO |
Model
|
HALO HSD | HALO HSD | HALO HSD | HALO HSD | HALO HSD |
Size
|
20 ft | 25 ft | 30 ft | 35 ft | 40 ft |
Folding (Multi-Section) or Non-Folding
|
Folding (Multi-Section) | Folding (Multi-Section) | Folding (Multi-Section) | Folding (Multi-Section) | Folding (Multi-Section) |
Fold Type
|
Folding 2 Piece Frame | Folding 2 Piece Frame | Folding 3 Piece Frame | Folding 3 Piece Frame | Folding 3 Piece Frame |
Dimensions and Weights
Working width, ft (m)
|
19 ft 1 in | 25 ft 1 in | 29 ft 2 in | 34 ft 1 in | 39 ft 1 in |
Transport width, ft (m)
|
12 ft 11 in w/ Rollers Ext. or 11 ft 3 in w/ Rollers Ret. | 12 ft 11 in w/ Rollers Ext. or 11 ft 3 in w/ Rollers Ret. | 13 ft 9 in w/ Rollers Ext. or 11 ft 11 in w/ Rollers Ret. | 13 ft 9 in w/ Rollers Ext. or 11 ft 11 in w/ Rollers Ret. | 13 ft 9 in w/ Rollers Ext. or 11 ft 11 in w/ Rollers Ret. |
Transport height, ft (m)
|
12 ft 6 in w/ Rollers Ext. or 13 ft 6 in w/ Rollers Ret. | 12 ft 7 in w/ Rollers Ext. or 13 ft 10 in w/ Rollers Ret. | 13 ft 5 in w/ Rollers Ext. or 14 ft 5 in w/ Rollers Ret. | 12 ft 11 in w/ Rollers Ext. or 14 ft w/ Rollers Ret. | 13 ft 3 in w/ Rollers Ext. or 14 ft 4 in w/ Rollers Ret. |
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
|
15440 lbs w/ Cage Roller or 18020 lbs w/ Otico Roller | 19300 lbs w/ Cage Roller or 22425 lbs w/ Otico Roller | 26100 lbs w/ Cage Roller or 29850 lbs w/ Otico Roller | 27800 lbs w/ Cage Roller or 32175 lbs w/ Otico Roller | 29100 lbs w/ Cage Roller or 33475 lbs w/ Otico Roller |
Other sizes available, number of widths
|
25ft, 30ft, 35ft, 40ft | 20ft, 30ft, 35ft, 40ft | 20ft, 25ft, 35ft, 40ft | 20ft, 25ft, 30ft, 40ft | 20ft, 25ft, 30ft, 35ft |
Ground Engaging Equipment - Front Row(s)
Front row(s) ground engaging equipment (description)
|
Smooth Low Concavity Blades | Smooth Low Concavity Blades | Smooth Low Concavity Blades | Smooth Low Concavity Blades | Smooth Low Concavity Blades |
Front row(s) ground engaging equipment (quantity)
|
1 | 1 | 1 | 1 | 1 |
Front row(s) equipment quantity
|
24 | 30 | 36 | 42 | 48 |
Front row(s) equipment mount
|
4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension |
Equipment spacing, in (mm)
|
10 in | 10 in | 10 in | 10 in | 10 in |
Equipment size, in (mm)
|
22 in | 22 in | 22 in | 22 in | 22 in |
Angle
|
14° open angle and 4° tipped under angle | 14° open angle and 4° tipped under angle | 14° open angle and 4° tipped under angle | 14° open angle and 4° tipped under angle | 14° open angle and 4° tipped under angle |
Bearings
|
Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs |
Ground Engaging Equipment - Rear Row(s)
Rear row(s) ground engaging equipment (description)
|
Notched Low Concavity Blades | Notched Low Concavity Blades | Notched Low Concavity Blades | Notched Low Concavity Blades | Notched Low Concavity Blades |
Rear row(s) ground engaging equipment (quantity)
|
- | - | - | - | - |
Rear row(s) equipment quantity
|
24 | 30 | 36 | 42 | 48 |
Rear row(s) equipment mount
|
4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension | 4pc rubber torsion suspension |
Equipment spacing, in (mm)
|
10 in | 10 in | 10 in | 10 in | 10 in |
Equipment size, in (mm)
|
22 in | 22 in | 22 in | 22 in | 22 in |
Angle
|
17° open angle and 4° tipped under angle | 17° open angle and 4° tipped under angle | 17° open angle and 4° tipped under angle | 17° open angle and 4° tipped under angle | 17° open angle and 4° tipped under angle |
Bearings
|
Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs | Multi-lip sealed, maintenance free hubs |
Equipment options
|
- | - | - | - | - |
Wheels and Tires
Transport wheel mounting
|
10-bolt | 10-bolt | 10-bolt | 10-bolt | 10-bolt |
Transport tires
|
600/50-22.5 Tires | 600/50-22.5 Tires | 600/50-22.5 Tires | 600/50-22.5 Tires (800/40-22.5 with Otico Roller Option) | 800/40-22.5 Tires |
Wing wheel mounting
|
N/A | N/A | N/A | N/A | N/A |
Wing tires
|
N/A | N/A | N/A | N/A | N/A |
Gauge wheel mounting
|
N/A | Mechanical gauge wheels | Mechanical gauge wheels | Mechanical gauge wheels | Mechanical gauge wheels |
Guage wheel tires
|
N/A | 13.5L-15X31 Tires | 500/50R17 Tires | 550/45-22.5 Tires | 550/45-22.5 Tires |
Hitch
Hookup to tractor, mounted or pull-type
|
CAT 3 or CAT 4 Standard or Ball Hitch | CAT 3 or CAT 4 Standard or Ball Hitch | CAT 3 or CAT 4 Standard or Ball Hitch | CAT 3 or CAT 4 Standard or Ball Hitch | CAT 3 or CAT 4 Standard or Ball Hitch |
Depth and Level Adjustment
Typical operating depth, in (mm)
|
2-5 in | 2-5 in | 2-5 in | 2-5 in | 2-5 in |
Operating speed (mph)
|
8-14 mph | 8-14 mph | 8-14 mph | 8-14 mph | 8-14 mph |
Depth control
|
Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control |
Fore/aft leveling
|
Hydraulic fore/aft leveling with accumulator protection | Hydraulic fore/aft leveling with accumulator protection | Hydraulic fore/aft leveling with accumulator protection | Hydraulic fore/aft leveling with accumulator protection | Hydraulic fore/aft leveling with accumulator protection |
Tractor Requirements
Required power, hp/ft (kw/m)
|
12-18 hp/ft | 12-18 hp/ft | 12-18 hp/ft | 12-18 hp/ft | 12-18 hp/ft |
Remote Hydraulic Values required
|
4 | 4 | 5 (includes hyd. Jack) | 5 (includes hyd. Jack) | 5 (includes hyd. Jack) |
Hydraulic Pressure
|
- | - | - | - | - |
Finishing Attachment Options
Option 1
|
23-inch Round Bar Cage Roller | Cage Roller | Cage Roller | Cage Roller | Cage Roller |
Option 2
|
Otico Wave-Profile FarmFlex Rubber Roller | Otico Wave-Profile FarmFlex Rubber Roller | Otico Wave-Profile FarmFlex Rubber Roller | Otico Wave-Profile FarmFlex Rubber Roller | Otico Wave-Profile FarmFlex Rubber Roller |
Option 3
|
Double 14-inch Flat Bar Rolling Basket | Double 14-inch Flat Bar Rolling Basket | Double 14-inch Flat Bar Rolling Basket | Double 14-inch Flat Bar Rolling Basket | Double 14-inch Flat Bar Rolling Basket |
Option 4
|
- | - | - | - | - |
