Independent Series I-4200

Features

The I-4200 is one of Salford’s next generation, patented, hybrid vertical tillage tools. Build for speed, performance and efficiency, the I-4200 is engineered with concave blades in the front and more wavy coulters in the rear rows to match the effects of both light discing and true vertical tillage in one pass. This design means the I-4200 is simply one of greatest soil finishers on the market. Designed to combine the residue mixing capabilities of a disc with the field finish characteristics of a cultivator – the Salford I-4200 is one of the most versatile tillage tools.

I-Series Indpendent Blades (4100-4200)The Independent Series I-4200 uses rubber suspension mounts with 22-inch shallow concave blades on the front two rows of blades. The back two rows use a 1 5/8-inch Coil-Tech Coulter II Mount with 22-inch 8-wave blades. Both blades are constructed from high-quality boron steel for durability and longevity in the toughest conditions. The independently mounted blades are capable of 5 inches of vertical travel providing excellent obstacle protecting and allows for the implement to travel at speeds of 8-12 mph. The I-4200’s 5-inch blade spacing uses the front two rows of concave blades to smooth ruts or uneven sections of the field while the back two rows chop and size residue for a superior finish whether in spring or fall.

Salford Coil-Tech Coulter Blade Hub Expanded to show it's internal seals, bearings and other components.Built tougher than competitors bearing systems. The hub can be greased and serviced, allowing for a longer life and lower operating costs. A 100-hour grease interval means you don’t spend long working on it. The double tapered cup and cone bearings handle side loads for operating in tough conditions. A multi-lip grease seal, grass wrap wear guard and blade scraper protect the hub and seals, even in wet and abrasive soil types.

Salford's I-Series tools have a sealed frame, with welded end caps for increased durability and longevity.The I-4200’s heavy duty construction uses a 4-inch by 6-inch tubular steel frame that provide in-field stability and durability. Depth can be easily set to adjust for varying field conditions with the single point depth control. In extremely tough soil conditions, optional 100 lbs weight kits can be added to the machine to achieve optimal ground penetration. The hydraulic level lift frame keeps the lifting cylinders in sync when changing depth and raising/lowering the machine. This ensures that all blades are achieving the same working depth and providing a level field finish and optimal planting conditions.

The I-4200 comes standard with a 14-inch diameter rolling basket and 3 rows of ½-inch diameter, 20-inch length harrows. The rolling basket provides improved re-sizing of soil clods and help to condition and anchor residue to the surface, helping to reduce erosion. The tine harrows are mounted on a parallel linkage which can be adjusted to multiple pitch settings for maximum down pressure and contouring to level and distribute residue. Both the rolling baskets and tine harrows can be adjusted hydraulicly with the Flex Finish option allowing you to adjust to varying field conditions from the cab.

Salford I-Series I-4200 with tow-hitch pulling packerSelect I-Series tools can be equipped with an optional tow hitch. The “one person” hitch is easy to connect to and features light wiring and connects with ease.
The hitch can be equipped with hydraulic lines for hydraulic fold and hydraulic powered implements.

Salford Independent Series I-4200 with switchblade shanks performing anhydrous applicationThe I-4200 is capable of being configured with Salford’s SwitchBlade Shank Kits. This allows you to equip your machine with shanks on 30-inch fertilizer for anhydrous application.

Salford's Valmar 6056 with Salford I-4200 hi-bred vertical tillage machineSalford I-Series tools prepare excellent seedbeds. This makes them an ideal for cover crop seeding with Salford’s Valmar 4056 and 6056 granular applicators. Seed cover crops at lower rates knowing you’ll have improved germination, while you’re managing residue and soil density.

Product Specs

Series
Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage Salford Tillage
Product Type
Independent Series Independent Series Independent Series Independent Series Independent Series Independent Series Independent Series Independent Series Independent Series Independent Series
Model
I-4200 I-4200 I-4200 I-4200 I-4200 I-4200 I-4200 I-4200 I-4200 I-4200
Size
12 ft 16 ft 20 ft 24 ft 28 ft 31 ft 36 ft 41 ft 41 ft* Bi-Folding 50 ft
Folding (Multi-Section) or Non-Folding
Non-Folding Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section) Folding (Multi-Section)
Fold Type
N/A 3-pc Flat Fold Single-Fold Wing Single-Fold Wing Single-Fold Wing Single-Fold Wing Single-Fold Wing Single-Fold Wing Bi-Fold Wing Bi-Fold Wing

Dimensions and Weights

Working width, ft (m)
12 ft 16 ft 20 ft 24 ft 28 ft 31 ft 36 ft 41 ft 41 ft* Bi-Folding 50 ft
Transport width, ft (m)
13 ft 3 in 11 ft 13 ft 10 in 13 ft 3 in 15 ft 8 in 15 ft 8 in 21 ft 21 ft 18 ft 9 in 19 ft
Transport height, ft (m)
N/A 10 ft 11 ft 2 in 12 ft 8 in 13 ft 14 ft 6 in 14 ft 2 in 16 ft 6 in 13 ft 6 in 14 ft 3 in
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
10500 lbs 14300 lbs 17400 lbs 19650 lbs 24100 lbs 24800 lbs 31800 lbs 34100 lbs 37250 lbs 47650 lbs
Other sizes available, number of widths
12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft 12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft

Ground Engaging Equipment - Front Row(s)

Front row(s) ground engaging equipment (description)
Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs Shallow Concave Discs
Front row(s) ground engaging equipment (quantity)
2 2 2 2 2 2 2 2 2 2
Front row(s) equipment quantity
9 11 15 17 21 23 27 31 31 39
Front row(s) equipment mount
Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts Rubber Suspension Mounts
Equipment spacing, in (mm)
5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in
Equipment size, in (mm)
22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in
Angle
14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle 14° open angle and 4° tipped under angle - - - - -
Bearings
5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing

Ground Engaging Equipment - Rear Row(s)

Rear row(s) ground engaging equipment (description)
Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave) Wavy Coulters (8 Wave)
Rear row(s) ground engaging equipment (quantity)
20 2 2 2 2 2 2 2 2 2
Rear row(s) equipment quantity
20 26 34 40 48 50 58 66 66 80
Rear row(s) equipment mount
Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts Coil-Tech II Blade Mounts
Equipment spacing, in (mm)
5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in 5 in
Equipment size, in (mm)
22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in 22 in
Angle
-
Bearings
5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing 5 Bolt Double Tapered Roller Bearing
Equipment options
- - - - - - - - - -

Wheels and Tires

Transport wheel mounting
6-bolt 8-bolt 8-bolt 8-bolt 8-bolt 8-bolt 8-bolt 8-bolt 10-bolt 10-bolt
Transport tires
11L x 15 “F” Tires 305/70x R22.5 Recapped Truck Tires 305/70x R22.5 Recapped Truck Tires 305/70x R22.5 Recapped Truck Tires 305/70x R22.5 Recapped Truck Tires 305/70x R22.5 Recapped Truck Tires 425-65R x 22.5 Recapped Truck Tires 425-65R x 22.5 Recapped Truck Tires 425-65R x 22.5 Recapped Truck Tires 445-65R x 22.5 Truck Tires (New)
Wing wheel mounting
N/A N/A 6-bolt 6-bolt 6-bolt 6-bolt 6-bolt 6-bolt 6-bolt 8-bolt
Wing tires
N/A N/A 11L x 15 load range “D” Tires 245 70r 19.5 245 70r 19.5 245 70r 19.5 11L x 15 load range “D” Tires 11L x 15 load range “D” Tires 11L x 15 load range “D” Tires 305/70 R22.5 Recapped Truck Tires
Gauge wheel mounting
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Guage wheel tires
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A

Hitch

Hookup to tractor, mounted or pull-type
Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch Category 3 or Category 4 Hitch

Depth and Level Adjustment

Typical operating depth, in (mm)
0-4 in 0-4 in 0-4 in 0-4 in 0-4 in 0-4 in 0-4 in 0-4 in 0-4 in 0-4 in
Operating speed (mph)
8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph 8-12 mph
Depth control
Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control Single point depth control
Fore/aft leveling
Turnbuckle hitch Turnbuckle hitch Turnbuckle hitch Turnbuckle hitch Hydraulic telescope hitch with cushion Hydraulic telescope hitch wit cushion Hydraulic telescope hitch with cushion Hydraulic telescope hitch with cushion Hydraulic telescope hitch with cushion Hydraulic telescope hitch with cushion

Tractor Requirements

Required power, hp/ft (kw/m)
15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft 15 hp/ft
Remote Hydraulic Values required
2 2 2 2 2 2 2 2 2 2
Hydraulic Pressure
- - - - - - - - - -

Finishing Attachment Options

Option 1
Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller Coil Tine & Single 14” Roller
Option 2
Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller Hydraulic Adjust Coil Tine & Manual 14" Roller
Option 3
Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller Manual Coil Tine & Hydraulic Lift Roller
Option 4
Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller Hyd. Adjust Coil Tine & Hydraulic Lift Roller

Compare

Select up to 3 products to compare specifications

Independent Series I-4200

Add Model & Size

Choose Model & Size

Product Specs

Series
Salford Tillage
Product Type
Independent Series
Model
I-4200
Size
12 ft
Folding (Multi-Section) or Non-Folding
Non-Folding
Fold Type
N/A

Dimensions and Weights

Working width, ft (m)
12 ft
Transport width, ft (m)
13 ft 3 in
Transport height, ft (m)
N/A
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
10500 lbs
Other sizes available, number of widths
12 ft, 16 ft, 20 ft, 24 ft, 28 ft, 31 ft, 36 ft, 41 ft, 50ft

Ground Engaging Equipment - Front Row(s)

Front row(s) ground engaging equipment (description)
Shallow Concave Discs
Front row(s) ground engaging equipment (quantity)
2
Front row(s) equipment quantity
9
Front row(s) equipment mount
Rubber Suspension Mounts
Equipment spacing, in (mm)
5 in
Equipment size, in (mm)
22 in
Angle
14° open angle and 4° tipped under angle
Bearings
5 Bolt Double Tapered Roller Bearing

Ground Engaging Equipment - Rear Row(s)

Rear row(s) ground engaging equipment (description)
Wavy Coulters (8 Wave)
Rear row(s) ground engaging equipment (quantity)
20
Rear row(s) equipment quantity
20
Rear row(s) equipment mount
Coil-Tech II Blade Mounts
Equipment spacing, in (mm)
5 in
Equipment size, in (mm)
22 in
Angle
Bearings
5 Bolt Double Tapered Roller Bearing
Equipment options
-

Wheels and Tires

Transport wheel mounting
6-bolt
Transport tires
11L x 15 “F” Tires
Wing wheel mounting
N/A
Wing tires
N/A
Gauge wheel mounting
N/A
Guage wheel tires
N/A

Hitch

Hookup to tractor, mounted or pull-type
Category 3 or Category 4 Hitch

Depth and Level Adjustment

Typical operating depth, in (mm)
0-4 in
Operating speed (mph)
8-12 mph
Depth control
Single point depth control
Fore/aft leveling
Turnbuckle hitch

Tractor Requirements

Required power, hp/ft (kw/m)
15 hp/ft
Remote Hydraulic Values required
2
Hydraulic Pressure
-

Finishing Attachment Options

Option 1
Coil Tine & Single 14” Roller
Option 2
Hydraulic Adjust Coil Tine & Manual 14" Roller
Option 3
Manual Coil Tine & Hydraulic Lift Roller
Option 4
Hyd. Adjust Coil Tine & Hydraulic Lift Roller
