AB200DSM Applicator for John Deere

Features

The industry’s largest and most efficient pneumatic applicator is equipped with an 80’ air boom that beats the competition by 14% in application width. The AB200DSM is engineered for the latest generation of Deere® 600R high clearance chassis and compatible with the 600R’s greater hydraulic capacity and fully integrates with the Greenstar® 4600 Command center with Spreadstar™ rate control. The self-propelled applicator is available with a two-compartment hopper to maximize application options and precision and the patented row crop boom can be equipped with application drop tubes on 30-inch centers.

AB200DS2The AB200DS2 has an 80-foot working width, engineered for stability at high operating speeds, spanning 14% more than the next largest pneumatic applicator available on the market. Air booms and funnels are factory calibrated. This makes for incredibly accurate application in the widest range of conditions.

The hydraulic boom suspension allows for greater in-field stability at higher operating speeds. The boom height can also be manually controlled by the operator to improve contouring in uneven terrain. The AB200DS has a higher, 69-inch boom clearance for post-emergence application later in the growing season and can be paired with optional drop tube kit on 30-inch centers for application in standing row crops.

185 cubic foot primary hopper with a 30 cubic foot micro-bin. The microbin uses secondary metering rollers that can be easily changed to achieve lower rates, or more accurately meter finer product. This system is ideal for micro-nutrients, granular crop protection products, or cover crops. Materials that are applied in lower rates and/or have very fine granules that require a more selective meter.

Like the split hopper, this bin configuration allows the user to fill the entire hopper with one product and apply. The internal gate in the micro-hopper can be can be opened, allowing product from the micro-bin to be diverted away from the meter roll and into the primary hopper.

Electric Tarp feature on AB200DSThe AB200DS hopper can be equipped with an electrically controlled tarp. The tarp can be opened and closed from within the cab using controls in the GreenStar 4600 CommandCenterTM or can be operated using the wireless remote included with the system.

4600 GreenStar CommandCenterPrescription variable rate control is handled through the GreenStar 4600 CommandCenterTM. With the integrated SpreadStarTM software, operators get a simple and intuitive interface. Left and right sections can be operated manually through the multi-function handle or automatically using sectional control. Fan on and off is activated through the CommandARMTM and uses PWM control through the SpreadStarTM controller.

Product Specs

Series
Valmar
Size
215 cu-ft
Product type
Chassis Mount Air Boom Applicators
Model Name Short
AB200DSM
Model Name Long
AB200DSM Applicator for John Deere High Clearance Chassis

Materials Spread

Fertilizer
Yes
AG Lime
No
Litter
No
Organics
No
Seed
Yes
Other
Granular Herbicide
Number of products applied, including optional hopper compartments
2

Detailed Equipment Specifications

Paint

Green

Hitch

N/A

Jack
N/A
Tarp

Standard: No Tarp
Option: Electric Tarp

Tail Light

Transport lighting and external LED work lights

Height
81" Unmounted
Weight
9,360 lbs

Hopper

Hopper Size

215 cubic foot 2 compartment hopper
185 cubic foot primary hopper, 30 cubic foot micro hopper

Hopper Material

Standard: 409 Stainless Steel, Painted

Hopper Extensions

N/A

Hopper Gate Control

N/A

Hopper Ladder

∙ Front ladder & platform
∙ 2nd hideaway maintenance ladder

Hopper "Inverted V"

Yes

Hopper Sight Window

Yes

Metering and Drive

PTO Drive

Chassis Supplied

Material Distribution Booms/Spinners/Air Line

∙ 80 foot spread / 304 stainless steel
∙ Hydraulic boom suspension w/accumulator
∙ 7 foot breakaway tips – hydraulic fold
∙ Integrated controls
∙ Hydraulic independent RH and LH fold

Application Swath Width

80 feet

Material Distribution Drive

17 inch S3 fan with pwm control

Metering Drive

Hydrualic driven metering via chassis supplied hydraulics

Primary Metering

Dual 14″ 304 stainless steel mesh chain conveyors (1 LH & 1 RH)

Primary Metering Minimum Output Rate

95 lbs/acre* at 10 mph, 65 lbs/cu-ft

Primary Metering Maximum Output Rate

750 lbs/acre* at 10 mph, 65 lbs/cu-ft

Secondary Metering

Optional: Roller Meter System for Micro-Nutrient Compartment

Secondary Metering Minimum Output Rate

Low Pegged Roller: 5 lbs/acre* Standard Pegged: 15 lbs/acre*

Secondary Metering Maximum Output Rate

Low Pegged Roller: 75 lbs/acre* Standard Pegged: 275 lbs/acre*

Material Banding or Section Control

Left/Right

Tires and Axles

Axle
-
Tire and Wheel Options
-

Monitoring and Precision Control

Monitors Options and Rate Control
-
Weigh System Option
-
