Salford field cultivators come loaded with features to improve performance and operation. Single point hydraulic depth control, hydraulic self-leveling frame and walking tandems are all standard features on Salford field cultivators. Optional heavy duty tow hitches all growers to pull a packer. The cultivators are engineered with oversized frames, axles and hinge points for years of dependable service and less down time.
Cultivators, S-Tine
Features
Salford S-tine cultivators have 4.5 inch tine spacing and come with a 4 inch long life, cast point. The s-tine has 20 inch under frame clearance. The s-tine has 110 – 200 pounds operating pressure. S-Tine tips pressure varies during operation as the tine vibrates in the soil, generating a more level finish.
Salford cultivators have heavy-duty frames with oversized hinge pins for durability and longevity. Salford’s durable frame design allows for an option hitch so that growers can pull packers or other field finishing tools.
The self-leveling frame sections of Salford cultivators follow ground contours exceptionally well. The unique frame design allows cultivators to remain level front to back and section to section as the machine follows ground undulations, providing reliable results in varying conditions.
Found on all Salford cultivators’ mainframe, primary wing, and secondary wings. The tandems ensure that shovels on each cultivator section run at even depth as the cultivator crosses uneven ground, providing exceptionally consistent results.
Salford S-tine Cultivators can be fitted with 4 finishing options.
Salford heavy duty tine harrows features a simple pitch adjustment setting to customize your filed finish and evenly distribute residue.
Salford rolling baskets are designed to size soil clods for good seed to soil contact.
- 2 rows of 3/8 tine harrow bars with double 11 inch rolling baskets
- 3 rows of 1/2 inch heavy duty tine harrow bars
- 3 rows of 1/2 inch heavy duty tine harrow bars and a single 11 inch rolling basket
- 3 rows of 1/2 inch heavy duty tine harrow bars and a single 14 inch rolling basket
Product Specs
Series
|
Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage | Salford Tillage |
Product Type
|
Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators | Cultivators |
Model
|
450 S-Tine | 450 S-Tine | 450 S-Tine | 450 S-Tine | 550 S-Tine | 550 S-Tine | 550 S-Tine | 550 S-Tine | 700 S-Tine | 700 S-Tine | 700 S-Tine |
Size
|
19 ft | 21 ft | 23 ft | 25 ft | 28 ft | 30 ft | 32 ft | 40 ft | 44 ft | 50 ft | 62 ft |
Folding (Multi-Section) or Non-Folding
|
Folding | Folding | Folding | Folding | Folding | Folding | Folding | Folding | Folding | Folding | Folding |
Fold Type
|
Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Single-Fold Wing | Bi-Fold Wing | Bi-Fold Wing |
Dimensions and Weights
Working width, ft (m)
|
19 ft (5.79 m) | 21 ft (6.40 m) | 23 ft (7.01 m) | 25 ft (7.62 m) | 28 ft (8.53 m) | 30 ft (9.14 m) | 32 ft (9.75 m) | 40 ft (12.19 m) | 44 ft (13.41 m) | 50 ft (15.24 m) | 62 ft (18.90 m) |
Transport width, ft (m)
|
12 ft 9 in (3.89 m) | 12 ft 9 in (3.89 m) | 12 ft 9 in (3.89 m) | 12 ft 9 in (3.89 m) | 15 ft 10 in (4.83 m) | 16 ft 4 in (4.98 m) | 18 ft 4 in (5.59 m) | 18 ft 11 in (5.77 m) | 18 ft 11 in (5.77 m) | 18 ft 11 in (5.77 m) | 20 ft 11 in (6.38 m) |
Transport height, ft (m)
|
11 ft 5 in (3.48 m) | 12 ft 3 in (3.73 m) | 13 ft (3.96 m) | 13 ft 8 in (4.17 m) | 12 ft 10 in (3.91 m) | 14 ft 2 in (4.32 m) | 13 ft 10 in (4.22 m) | 12 ft 3 in (3.73 m) | 14 ft 4 in (4.37 m) | 14 ft 4 in (4.37 m) | 15 ft 6 in (4.72 m) |
Approximate weight, lb (kg) (w/ Standard harrows unless stated otherwise)
|
7,700 lbs (without harrows) (3,492.70 kg) | 7,900 lbs (without harrows) (3,492.70 kg) | 8,300 lbs (without harrows) (3,764.87 kg) | 8,600 lbs (without harrows) (3,900.89 kg) | 9,075 lbs (without harrows) (4,115.06 kg) | 9,725 lbs (without harrows) (4,411.88 kg) | 10,370 lbs (without harrows) (4,703.47 kg) | 13,650 lbs (without harrows) (6,191.06 kg) | 15,980 lbs (without harrows) (7,249.89 kg) | 17,710 lbs (without harrows) (8,035.04 kg) | 21,500 lbs (without harrows) (9,752.22 kg) |
Other sizes available, number of widths
|
21ft, 23ft, 25ft, 28ft, 30ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 23ft, 25ft, 28ft, 30ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 25ft, 28ft, 30ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 28ft, 30ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 30ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 32ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 30ft, 40ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 30ft, 32ft, 44ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 30ft, 32ft, 40ft, 50ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 30ft, 32ft, 40ft, 44ft, 62ft | 19ft, 21ft, 23ft, 25ft, 28ft, 30ft, 32ft, 40ft, 44ft, 50ft |
Ground Engaging Equipment - Front Row(s)
Front row(s) ground engaging equipment (description)
|
S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine |
Front row(s) ground engaging equipment (quantity)
|
2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Front row(s) equipment quantity
|
21 | 23 | 24 | 27 | 31 | 32 | 35 | 44 | 47 | 53 | 66 |
Front row(s) equipment mount
|
S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance |
Equipment spacing, in (mm)
|
4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) |
Equipment size, in (mm)
|
4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point |
Angle
|
- | - | - | - | - | - | - | - | - | - | - |
Bearings
|
- | - | - | - | - | - | - | - | - | - | - |
Ground Engaging Equipment - Rear Row(s)
Rear row(s) ground engaging equipment (description)
|
S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine | S-Tine |
Rear row(s) ground engaging equipment (quantity)
|
3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Rear row(s) equipment quantity
|
31 | 33 | 36 | 39 | 45 | 48 | 51 | 64 | 69 | 79 | 98 |
Rear row(s) equipment mount
|
S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance | S-tine with 110 lbs – 200 lbs (49.90-90.72 kg) operating pressure, 20 in (508 mm) under frame clearance |
Equipment spacing, in (mm)
|
4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) | 4.5 in (114.3 mm) |
Equipment size, in (mm)
|
4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point | 4 in (101.6 mm) Long Life Cast Point |
Angle
|
- | - | - | - | - | - | - | - | - | - | - |
Bearings
|
- | - | - | - | - | - | - | - | - | - | - |
Equipment options
|
Tow Hitch | Tow Hitch | Tow Hitch | Tow Hitch | Tow Hitch | Tow Hitch | Tow Hitch | Tow Hitch, "Land Hugger” Floating Frame with manual adjust caster wheel | Tow Hitch, "Land Hugger” Floating Frame with manual adjust caster wheel | Tow Hitch, "Land Hugger” Floating Frame with manual adjust caster wheel | Tow Hitch, "Land Hugger” Floating Frame with manual adjust caster wheel |
Wheels and Tires
Transport wheel mounting
|
6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 8-bolt | 8-bolt | 8-bolt | 8-bolt |
Transport tires
|
11L x 15 load range "C" Tires | 11L x 15 load range “C” Tires | 11L x 15 load range "C" Tires | 6-bolt 11L x 15 load range “C” Tires | 11L x 15 load range “F” Tires | 11L x 15 load range "F" Tires | 11L x 15 load range "F" Tires | 12.5 x 15 Highway Service load range "F" Tires | 340/60 R16.5 Radial Implement Tires | 340/60 R16.5 Radial Implement Tires | 340/60 R16.5 Radial Implement Tires |
Wing wheel mounting
|
6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt | 6-bolt |
Wing tires
|
11L x 15 load range “C” Tires | 11L x 15 load range “C” Tires | 11L x 15 load range "C" Tires | 11L x 15 load range “C” Tires | 11L x 15 load range “C” Tires | 11L x 15 load range "C" Tires | 11L x 15 load range "C" Tires | 11L x 15 load range "C" Tires | 11L x 15 load range "C" Tires | 11L x 15 load range "C" Tires | 11L x 15 load range "C" Tires |
Gauge wheel mounting
|
N/A | N/A | N/A | N/A | Manual adjustable gauge wheels on primary wing only | Manual adjustable gauge wheels on primary wing only | Manual adjustable gauge wheels on primary wing only | Manual adjustable gauge wheels on primary wing only | Manual adjustable gauge wheels on primary wing only | Manual adjustable gauge wheels on both wings | Manual adjustable gauge wheels on both wings |
Guage wheel tires
|
N/A | N/A | N/A | N/A | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires | 11L x 15 load range "D" Tires |
Hitch
Hookup to tractor, mounted or pull-type
|
Cast hitch cat. 3 with clevis adapter | Cast hitch cat. 3 with clevis adapter | Cast hitch cat. 3 with clevis adapter | Category 3 hitch with bolt in adapter or Category 4 single clevis | Category 3 hitch with bolt in adapter or Category 4 single clevis | Category 3 hitch with bolt in adapter or Category 4 single clevis | Category 4 Single clevis hitch | Category 4 Single clevis Hitch | Category 4 Single clevis Hitch | Category 4 Single clevis hitch | Category 4 Single clevis hitch |
Depth and Level Adjustment
Typical operating depth, in (mm)
|
1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) | 1.5-4 in (38.1-101.6 mm) |
Operating speed (mph)
|
5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph | 5.5-9 mph |
Depth control
|
Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control | Single point depth control |
Fore/aft leveling
|
- | - | - | - | - | - | - | - | - | - | - |
Tractor Requirements
Required power, hp/ft (kw/m)
|
5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21- 14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) | 5-6 hp/ft (12.21-14.65 kW/m) |
Remote Hydraulic Values required
|
2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Hydraulic Pressure
|
- | - | - | - | - | - | - | - | - | - | - |
Finishing Attachment Options
Option 1
|
2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller | 2 Bar 3/8 in Tine & Double 11 in Roller |
Option 2
|
3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine | 3 Bar 1/2 in HD Tine |
Option 3
|
3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller | 3 Bar HD 1/2 in Tine with Single 11 in Roller |
Option 4
|
3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller | 3 Bar HD 1/2 in Tine with Single 14 in Roller |
