Grasshopper Spinner Spreader

Application • Pull Type Spinner Spreaders

Features

The Grasshopper pull-type spreader is the original mid-season, top-dress applicator from Salford. Designed to hold 5 tons of fertilizer or 7 tons of lime, this machine delivers the nutrients your emergent crop needs to maximize yield potential. With high ground-clearance for row cropping and top dressing and flotation tires to minimizing soil compaction, this spreader achieves precision application in both row crop and sod/turf farm environments. The Grasshopper is built for durability and precision, featuring ground-wheel-drive mechanics, and the original Salford spreader system for a consistently wider, flatter spread pattern.

• Choice of PTO (Series 6 CV Joint, shielded drive) or hydraulic driven spinners (OH mounted motors)
• 24″ dished spinner design for precision coverage
• Stainless steel spinners, fins and spread shield
• 9′ Stainless steel hopper with Ladder
• Laser Cut Sight Window
• Jack Operated Gate
• Stainless Steel mesh chain conveyor
• UHMW comb cover
• 12-Ton rigid, high-clearance axle with 11.25 x 28 ribbed implement row crop tires
• High ground clearance from row-cropping and top dressing
• 64″-72″ reversible track width
• Heavy-duty tongue jack

Contact Us Form

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Need some tech support?
Find your equipment's Manual here. Check out the How-To Videos page for tips and tricks on operating and maintaining your Salford equipment, and explore our How-To Blog posts for even more helpful resources.

First Name * Last Name *

Phone Number*

Email*

State/Provice*

Postal code*

How can we help you?*

Salford Model Line*

Serial Number

Message to Salford

Specs Compare

Product Specs

Series	BBI
Product type	Pull Type Spinner Spreaders
Model	Grasshopper
Size	180 cu-ft (5.09 cu-m)

Dimensions and Weights

Metering and Drive

PTO Drive	Standard: 540 RPM Series 6 CV Joint PTO Shaft 1000 RPM Series 6 CV 1 3/4 20 Spline 1000 RPM Series 6 CV 1 3/8 21 Spline No PTO – Plug to Tractor
Material Distribution Booms/Spinners/Air Line	24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield
Application Swath Width, ft (m)	Lime: Up to 60 feet (18.29 m) Fert: Up to 80 feet (24.38 m)
Material Distribution Drive	Standard:PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI
Metering Drive	#60 stainless steel ground drive chain Standard: Press Wheel Pneumatic Tire Optonal: Metal Press Wheel
Primary Metering	Standard: 20 inch Stainless Steel Mesh Chain
Primary Metering Minimum Output Rate	-
Primary Metering Maximum Output Rate	-
Secondary Metering	N/A
Secondary Metering Minimum Output Rate	-
Secondary Metering Maximum Output Rate	-
Material Banding or Section Control	N/A

Compare

Select up to 3 products to compare specifications

Grasshopper Spinner Spreader

Add Model & Size

Choose Model & Size

1 2

Product Specs

Series	BBI
Product type	Pull Type Spinner Spreaders
Model	Grasshopper
Size	180 cu-ft (5.09 cu-m)

Dimensions and Weights

Metering and Drive

PTO Drive	Standard: 540 RPM Series 6 CV Joint PTO Shaft 1000 RPM Series 6 CV 1 3/4 20 Spline 1000 RPM Series 6 CV 1 3/8 21 Spline No PTO – Plug to Tractor
Material Distribution Booms/Spinners/Air Line	24 inch dished spinner design for precision coverage Stainless steel spinners, fins and spread shield
Application Swath Width, ft (m)	Lime: Up to 60 feet (18.29 m) Fert: Up to 80 feet (24.38 m)
Material Distribution Drive	Standard:PTO Driven Spinners Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI
Metering Drive	#60 stainless steel ground drive chain Standard: Press Wheel Pneumatic Tire Optonal: Metal Press Wheel
Primary Metering	Standard: 20 inch Stainless Steel Mesh Chain
Primary Metering Minimum Output Rate	-
Primary Metering Maximum Output Rate	-
Secondary Metering	N/A
Secondary Metering Minimum Output Rate	-
Secondary Metering Maximum Output Rate	-
Material Banding or Section Control	N/A

Specification Details & Conditions:

Specifications are subject to change without notice. All weights, dimensions, and other specification values listed are for standard equipment. Optional features, configurations, and machine settings may alter these values, including transport dimensions. Where specifications vary by equipment setting, the minimum value will be used unless otherwise stated. For the most accurate and up-to-date information, please contact your dealer or our customer support team.

Explore More

Downloads

BBI Spreaders Literature

English

Click to Download

BBI Spreaders Literature

French

Click to Download

PARTS AND SERVICE

Parts Look-up

Click Here to Look-Up Parts

Working width, ft (m)	N/A
Transport width, ft (m)	-
Transport height, ft (m)	7 ft 3 in (2.21 m)
Approximate weight, lb (kg)	-
Other sizes available, number of capacities	-

Fertilizer	YES
AG Lime	YES
Litter	NO
Organics	NO
Seed	NO
Other	-
Number of products applied, including optional hopper compartments	1

Hopper Size	9 feet Standard Body Hopper – 180 cu-ft (5.09 cu-m)
Hopper Material	Standard: 409 Stainless Steel, Painted or 304 Stainless Steel
Hopper Extensions	N/A
Hopper Gate Control	Jack Operated Gate
Hopper Ladder	Standard: Hopper Ladder
Hopper "Inverted V"	N/A
Hopper Sight Window	Standard Sight Window

Transport wheel mounting	12-Ton rigid, high clearance axle for row-cropping and top dressing and 72" track width (68" - 80" track available on request)
Transport tires	Standard: 11.25" x 28" Tires and Wheels Optional: 440/80R28 Tires & 15 x 28 Wheels

Option 1	Paint Options: Standard: Red Optional: Green, Grey or Black Accent Parts (304 SS)
Option 2	Standard: No Trap Optional: 9 foot Tarp with Aluminum End Caps
Option 3	Standard: No Tail Lights Optional: Rear Tail Lights with Turn Signal, Side Markers and Wiring Kit
Option 4	-
Equipment Options	-

Grasshopper Spinner Spreader
