Features

Salford’s BBI Liberty pull-type spreader is the ideal medium capacity machine for fertilizer and lime applications with unprecedented precision thanks to the original Salford spreader system. This 10’ long, tandem-axle frame is built to be the toughest, most durable spreader in the market, delivering the most efficient fertilizer and lime field application to save time and money. The Liberty 24” dished spinner is designed for precision coverage and is available in heavy-duty, high-capacity packages and low-profile units.

• Choice of PTO (Series 6 CV Joint, shielded drive) or hydraulic driven spinners (OH mounted motors)
• 24″ dished spinner design for precision coverage
• Stainless steel spinners, fins and spread shield
• 10′ Stainless steel hopper
• 20″ stainless steel mesh chain conveyor
• UHMW comb cover
• 7-Ton “Torsion-Flex” tandem axle with 12.5 X 15 implement tires
• Heavy-duty tongue jack

Liberty Powerful MechanicsLiberty is a mechanical field dynamo, featuring a ground-wheel-drive conveyor. The Liberty fertilizer and lime spreader gets its ample power from PTO or hydraulic-driven spinners, getting the job done on small to mid-sized farms.

Liberty pull-type spreaders are designed to be the toughest, most durable fertilizer and lime spreaders in the market. With BBI’s rugged design and construction, you can more efficiently spread your fields, saving you time and money.

Liberty Medium CapacityAt 10 feet, sitting on a tandem-axle frame, Liberty is ready for a variety of medium-capacity nutrient applications. Control your economic destiny and own your yield with Liberty, featuring the original Salford spreader system, now featured on the company’s wider range of hydraulic models.

  • Heavy-duty, high-capacity packages and low-profile units are available

  • “Inverted V” option for heavy materials such as lime

  • Overhead spinner motors above the chemical, resulting in extended motor life

  • UHMW and stainless steel construction reduce corrosion issues and extend spreader life

  • Payload packages available from 5-9 tons

  • Distribution of granular fertilizer or lime

  • Variety of applications

  • Ground wheel drive conveyor

  • PTO or hydraulic-driven spinners

  • Proprietary BBI spreader system

  • Delivers a wider, flatter, more consistent pattern

  • Dual rack and pinion gate prevents jams

  • One-piece CNC machined comb gives longer chain life

Product Specs

Series
BBI
Size
200 cu-ft capacity or 220 cu-ft capacity
Product type
Pull Type Spinner Spreaders
Model Name Short
Liberty
Model Name Long
Liberty, Mechanical, 10' Tandem Axle Spreader

Materials Spread

Fertilizer
YES
AG Lime
YES
Litter
NO
Organics
NO
Seed
No
Other
-
Number of products applied, including optional hopper compartments
1

Detailed Equipment Specifications

Paint

Standard Paint Color – Red
Optional Paint Color – Green
Optional Paint Color – Gray
Optional Paint Color – Black Accent Parts (304 SS)

Hitch

Standard: Cat 3 Cast Hitch – includes Pintle and Clevis Hitch
Optional: Cat 4 Articulating Hitch

Jack
Heavy-duty tongue jack
Tarp

Standard: No Tarp
Option: 10′ Tarp for Standard or high Profile Hoppers Aluminum End Caps
Option: 10′ Tarp for for Standard or High Profile Hoppers Stainless End Caps

Tail Light

Standard: No Tail Lights
Optional: Rear Tail Lights with Turn Signal, Side Markers, Wired with Corrosion Resistant Wiring Kit

Height
-
Weight
6,000 lbs

Hopper

Hopper Size

Choice:
10′ Standard Profile Hopper 200 cu-ft capacity
10′ High Profile Hopper 220 cu-ft capacity

Hopper Material

Choice: 409 Stainless Steel, Painted
Choice: 304 Stainless Steel

Hopper Extensions

Standard: No Extension Brackets
Optional: Extension Brackets for 6″ boards

Hopper Gate Control

Jack Operated Gate

Hopper Ladder

Standard: No Hopper Ladder
Optional: Ladder for Carbon Steel Hopper
Optional: Ladder for Stainless Steel Hopper

Hopper "Inverted V"

Optional

Hopper Sight Window

Standard Sight Window

Metering and Drive

PTO Drive

Choice:
540 RPM Series 6 CV Joint PTO Shaft
1000 RPM Series 6 CV 1 3/4 20 Spline
1000 RPM Series 6 CV 1 3/8 21 Spline

Material Distribution Booms/Spinners/Air Line

24″ dished spinner design for precision coverage
Stainless steel spinners, fins and spread shield

Application Swath Width

Lime: Up to 60 feet Fert: Up to 80 feet

Material Distribution Drive

Standard:PTO Driven Spinners
Optional: Hydraulic Plug-To-Tractor Spinners (Plug-To-Tractor), requires 21 GPM @ 2000 PSI

Metering Drive

#60 stainless steel ground drive chain
Standard: Press Wheel Pneumatic Tire
Optonal: Metal Press Wheel

Primary Metering

20″ Stainless Steel Mesh Chain

Primary Metering Minimum Output Rate
-
Primary Metering Maximum Output Rate
-
Secondary Metering

N/A

Secondary Metering Minimum Output Rate
-
Secondary Metering Maximum Output Rate
-
Material Banding or Section Control

N/A

Tires and Axles

Axle
  • • Standard: 7 Ton Torsion Tandem Axle (12.5L X 15 implement tires with 6-Bolt Hub)
  • • Optional: 9 Ton Heavy Duty Tandem Axle (16.5 X 16.1 R3 tires and 8-Bolt Hub, 10,000 lb axles)
  • • Optional: 10 Ton Walking Beam (16.5L X 16.1 R3 Tires and 8-Bolt Hub)
    Includes Heavy Duty Jack
  • • Optional: 14 Ton Walking Beam (21.5L X 16.1 R3 Tires and 10-Bolt Hub)
    Includes Series 6 CV Joint PTO shaft, Heavy Duty Jack
  • • Optional: 20 Ton Walking Beam (800/65R32 Tire and 10-Bolt Hub)
    Includes Tubular Trailer Frame. CV Joint PTO shaft series
Tire and Wheel Options
  • Standard:
  • • 12.5L x 15 Tires and 6-Bolt Wheel for 7-Ton suspension
  • • 16.5L x 16.1 R3 Tires and 8-Bolt Wheel (Standard for 9 / 10 Ton suspensions)
  • • 21.5L x 16.1 R3 Floatation Tire and 10 Bolt Wheel (Standard for 14 Ton suspensions)
  • Optional:
  • • 16.5L x 16.1 Ribbed Implement Tires / 8-Bolt Wheel (Optional for 9 / 10 Ton suspensions)
  • • 21.5L x 16.1 Ribbed Implement Floatation Tire and 10 Bolt Wheel (Optional for 14 Ton suspensions)
  • • 700/40-22.5/16 1-3 Tires in lieu of 21.5L x 16.1 (14-Ton suspension only)
  • • 14L x 16.1 Flotation Tires in lieu of 12.5L x 15
  • • 19L x 16.1 Flotation Tires in lieu of 16.5L x 16.1
  • • 21.5L x 16.1 R3 Flotation Tires in lieu of 16.5L x 16.1
  • • 21.5L x 16.1 Ribbed Implement Flotation Tires in lieu of 16.5L x 16.1
  • • 500/45-22.5 Tires in lieu of 16.5L x 16.1
  • • 550/60-22.5 Tires in lieu of 21.5L x 16.1

Monitoring and Precision Control

Monitors Options and Rate Control
-
Weigh System Option
-
